Set consists of RF20 EPM handheld transceiver and accessories. The RF20 multiband transceiver with improved resistance to electronic warfare is designated for use at the lowest tactical command levels for all kinds of military units. Depending on the type of selected frequency band, the transceiver is able to communicate in HF band with frequency modulation, with VHF RF13 transceivers, RF2350, RF2050 mobile transceivers and with airborne transceivers in Aircraft band I. For more details on RF20 transceiver and other set components see relevant pages of this website.

PN (RN): 2300.000.10
Návod k obsluze RF1302E 2300.010.11
Krátký návod k obsluze RF1302E 2300.011.11
Záznamník 6000002011
Technický list 6000002021
Switch display: Catalog / List
Sort by

RF20 - EPM handheld transceiver

PN (RN): 2300.100.10

RF20 EPM handheld multiband transceiver with improved resistance to electronic warfare for use at the tactical command levels for all kinds of military units.

  • standard range of functionalities typical for handheld transceivers of RF20 system

LP1302 - Battery pack

PN (RN): 7029.100.02

Power supply for RF20 radio system transceivers. The battery pack consists of serial-parallel set of four LiIon cells with protective diagnostic circuits, and a capacity display.

  • nominal capacity 3.6 Ah

AS1301 - Short tape antenna 0.5 m

PN (RN): 2038.100.01
KČM: 0064681101058
NSN: 5985160025492

Short-distance communication between RF20 or RF1301 transceivers. This antenna can also be used with the RF13 transceiver. The antenna proper...

AL1301 - Long tape antenna 1.1 m

PN (RN): 2037.100.01
KČM: 0064681101236
NSN: 5985160015375

This is a basic type antenna for RF20 or RF1301 transceivers. This antenna can also be used with the RF13...

Transceiver bag

PN (RN): 6000010032
KČM: 0067100045353
NSN: 5820160044342

Set bag

PN (RN): 6000010033
KČM: 0067100045346
NSN: 5820160044343

Battery pack bag

PN (RN): 7020.116.01
KČM: 0064725000813
NSN: 5895160015377
Type designation Name PN (RN) KCM NSN
RF20 EPM handheld transceiver 2300.100.10
LP1302 Battery pack 7029.100.02
AS1301 Short tape antenna 0.5 m 2038.100.01 0064681101058 5985160025492
AL1301 Long tape antenna 1.1 m 2037.100.01 0064681101236 5985160015375
Transceiver bag 6000010032 0067100045353 5820160044342
Set bag 6000010033 0067100045346 5820160044343
Battery pack bag 7020.116.01 0064725000813 5895160015377
