Assembly, placement, debugging, testing and installation of electronics according to specifications
Our customers are able to use all our strengths for their products.
- Advanced manufacturing equipment
- Software for manufacturing process control
- Highly qualified workers
- Many years of experience
- Quality control and standards compliance
- Fast order processing
- Precise and reliable solutions
Automated PCB assembly
Automated PCB assembly
Modern technology, precision and speed
PCB component placement is performed on a modern automated line with high precision, speed and automated optical inspection.
Non-contact application of solder paste utilising MYDATA MY500
- Solder paste or adhesive application without a stencil
- High speed of up to 30,000 components per hour (IPC9850)
Automated component placement by SAMSUNG SM421
- Placement speed of 21,000 components per hour (as per IPC9850)
- Precise placement head with an accuracy of ± 0.05mm
HELLER 1707 MKIII oven for reflowing
- It contains 7 heated zones with adjustable temperature of up to 350°C and 1 cooling zone.
- The oven is also suitable for lead-free soldering
- Fully automated soldering process
Automated optical inspection performed by MIRTEC MV-3 inspection equipment
- It also provides data for statistical process control (SPC).
- Inspection speed of 32cm2/s
Basic parameters for component placement
Basic parameters for component placement
Placement deviation as low as ± 0.03mm
PCB dimensions ranging from 85 x 50mm to 400 x 330mm, with a thickness of 0.5 to 3mm
Component placement packages ranging from 0201 (0.6 x 0.3mm) to QFP, BGA with a 40mm long edge
Accuracy of placement for chip components ± 0.05mm, for fine pitch components ± 0.03mm
SnPb solder based and lead-free soldering technology
Application of no-clean solder pastes based on SnPb, SnPbAg, SnAgCu
Standard electronics assembly
Standard electronics assembly
Employee experience and production process control software
Apart from the automatic component placement line, we also have technical and human resources for the standard assembly of electronics. Our workers are experienced in THT assembly and mounting of electronic sub-assemblies; all production sites meet ESD requirements.
Furthermore, we perform debugging, testing and installation of products according to customer requirements. Final inspections are a matter of course. Before shipping products, we ensure first-rate packing for the safe delivery of your shipment.
Requirements for contract implementation
- Data file for creation of paste printing software for PROTEL, ALTIUM (ASCII format), or a GERBER file for soldering layer
- Printed circuit board assembly drawing DWG, JPG, BMP, PDF, PS
- Text file with components' coordinates
- List of components
- Any special requirements for the component supplier, including ESD requirements
- The PCB should be designed for automated component placement (line-up points, technological environment)
